贴片0603系列
贴片保险丝 0603 0603FA系列
[编辑：品安电子专业保险丝供应商] [时间:2014-10-13]
| Catalog Number |
0603FA  |
| Dimensions | See Data Sheet 4336 |
| Volts |
50Vdc (250 mA-500mA) 32Vdc (750 mA-5A) 32Vac (500 mA-5A) |
| Amps | 250mA- 5A |
| Interrupting Rating |
50A@ 50vdc 250-375mA 35A@ 50dc 500mA 50A@ 32Vac/dc 750- 1 A 35A@ 32Vac/dc 1.25-5A |
| Agency Information |
• UL Recognition Guide & File numbers: JDYX2 &E19180 • CSA Component Acceptance: 053787 C 000 & Class Number: 1422 30 |
| Ordering | Specify packaging and product code (i.e., TR/0603FA250-R) |
| Packaging | TR - 5000 fuses on paper tape and reeled on a 178mm (7 inch) diameter reel per EIA Standard 481-1 |
